ARC Technical Data Sheet | CRX Technical Data Sheet

ARC Technical Data Sheet


Kynar Aquatec® ARC latex is a hybrid dispersion containing, on polymer solids, 70% (wt) Kynar® PVDF resin, and 30% (wt) proprietary acrylic resin, produced without any fluorinated surfactants or alkylphenol ethoxylate (APEO). After more than 14 years of south Florida exposure, waterborne coatings based on Kynar Aquatec® ARC latex confirm weathering performance comparable to 70% Kynar 500® PVDF finishes, similar to those used in OEM baked metal finishes. Kynar Aquatec® ARC is highly reccomended for applications of field applied topcoats for metal roofing and façade restoration where the highest UV performance is required.

TECHNICAL PROPERTIES VALUE
Appearance Milky White, Fluid Emulsion
% Solids (by weight) 44
% Solids (by volume) 34
Minimum Film Formation Temperature MFFT (°C) 27
pH 8.0
Dry Density (g/mL) 1.50
Wet Density (g/mL) 1.178
Fluoropolymer/Acrylic Resin Ratio 70:30
% VOC (as supplied) <1
Viscosity (Brookfield 30 s-1) 100
Odor Mild/Neutral
Shelf Life (protect from freezing) 18 mos.

Note: These are typical properties, not specifications

COMMON APPLICATIONS KYNAR AQUATEC® ARC

  1. Architectural Coatings
  2. PVC lineals (Formulated to meet AAMA 615)
  3. Metal façade restoration (Formulated to meet AAMA 2605 or Qualicoat 3)

Field-applied topcoat for metal roofing

Please consult Arkema’s disclaimer regarding the use of Arkema’s products at http://www.arkema.com/en/products/product-safety/disclaimer/ Contact information: Arkema Inc. Headquarters Arkema France
Kynar® and Kynar Aquatec® are registered trademarks of Arkema Inc. China: +86 21 6147 6888 900 First Avenue 420 rue d’Estienne d’Orves
© 2019 Arkema Inc. All rights reserved. Japan: +81 3 5251 9663 King of Prussia, PA 19406, USA 92705 Colombes Cedex - France
Korea: +82 2 37036853 Tel.: (+1) 610-205-7000 Tel: +33 (0)1 49 00 80 80
ExtremeMaterials.com KynarAquatec.com Singapore: +65 6419 9018 Taiwan: +886 2 2747 6979 India: +91 22 663750 Fax: +33 (0)1 49 00 83 96





CRX Technical Data Sheet



Kynar Aquatec® CRX latex is a hybrid dispersion containing, on polymer solids, 70% (wt.) Kynar® PVDF resin, and 30% (wt.) proprietary acrylic resin with free hydroxyl and acid functionality for 2K coating systems. Kynar Aquatec® CRX latex enhances early coating hardness, solvent resistance, adhesion and scratch resistance in addition to outstanding weatherability. Kynar Aquatec® CRX is produced without any fluorinated surfactants or alkylphenol ethoxylate (APEO).

TECHNICAL PROPERTIES VALUE
Appearance Milky White,Fluid Emulsion
% Solids (by weight) 44
Minimum Film Formation Temperature MFFT (°C) 15
pH 8.0
Wet Density (g/mL) 1.18
Fluoropolymer/Acrylic Resin Ratio 70:30
% VOC (as supplied) <2
Viscosity (Brookfield 30 s-1) 100
Odor Mild/Neutral
Stabilization Anionic
OH equivalent wt., on solids 3178 (%OH = 0.53)
OH equivalent wt., on total wet 7222 (%OH = 0.24)
COOH equivalent wt., on solids 9900 (Acid# = 5.7)
Shelf Life (protect from freezing) 18 mos.

Note: These are typical properties, not specifications

COMMON APPLICATIONS KYNAR AQUATEC® CRX
